Input voltage(V): 6 – 27.

Maximum current(A): 43.

Input level(V): 3.3 – 5.

Duty cycle: 0 – 100%.

Path resistance: 16 mΩ at 25°C.

Low quiescent current: 7 µA at 25°C.

Double BTS7960 43A H-Bridge High-Power Stepper Motor Driver Module

Input Voltage: 9V - 60V DC

Output Current: Up to 20A

Control Method: Pulse Width Modulation (PWM)

Direction Control: Yes (for models with this feature)

Operating Temperature: -10°C to 60°C

DC Motor Controller, DC 9-60V 20A DC Electric Motor Speeds Controller Board PWM Motor Speeds Regulator

CNC Machinery: Used for controlling the movement of cutting tools and other components in CNC routers, mills, and similar machinery.

3D Printing: Commonly employed in 3D printers to move the print head, build platform, and other components to create precise 3D objects.

Robotics: Utilized in robotics for controlling the movement of robot joints, arms, and other components.

Automation: Found in various automation systems for tasks such as conveyor belt control and camera positioning.

17HS8401 48mm Nema 17 Stepper Motor 42 Motor 1.8A 52N.cm 4-lead for CNC 3D Printer

Supply Voltage: 12V

Standard interfaces (as that of the extruder)

Reserved GCI like I2C and RS232

3 MOSFET’s are applied to the heater/ fan and thermistor circuit.

Another 5A added to protect the component parts.

An 11A fuse is added to the hotbed.

Support 5 stepper drive board\

RAMPS 1.4 3D Printer Controller Board Arduino Mega Shield

L9110S-chip motor drive

Supply voltage: 2.5-12V

The maximum operating current of 0.8A

Drive two DC motors or a 4-wire 2-phase stepping motor.

Ultra-small size, suitable for assembly

L9110S Dual Channel H-Bridge Motor Driver Module

Supply Voltage: 8.2 – 42 VDC.

Current Capacity : 2.2A max(24V).

Continuous current per phase: 1.5 A.

Minimum Logic voltage: 2.5V.

Maximum Logic Voltage: 5V.

Microstep resolutions: full, 1/2, 1/4, 1/8, 1/16, and 1/32.

DRV8825 Stepper Motor Driver Module
