74HC08 Quad 2-Input AND Gate IC (7408 IC) DIP-14 Package

SKU: 000683

In Stock

~~₹26.00~~ ₹15.00

In Stock

Add to Wishlist

Compare

Type: DIP Bipolar
Voltage Rating: 2.0 to 6.0V
Temperature Rating: 0 to 70Deg C
Number of: 14 Pins
Mounting: Through Hole
74HC08 Quad 2-Input AND Gate IC (7408 IC) DIP-14 Package

Description

Quad AND Gates: The 74HC08 IC includes four separate AND gates in a single package.
Two Inputs: Each AND gate has two inputs (A and B) that are used to perform the logical operation.
AND Logic: The AND gate produces an output that is HIGH (1) only when both inputs are HIGH (1). In all other cases, the output is LOW (0).

Additional information

Weight	0.2 kg

Reviews

There are no reviews yet

Only logged in customers who have purchased this product may leave a review.
