Description

6-12V 320A Waterproof Brushed Motor ESC

6-12V 320A Waterproof Brushed Motor ESC suitable for RC cars, boats, or ships, supporting both 2-3S LiPo and 5-9 cell NiMH batteries, and capable of very high (likely overstated) current ratings in a compact package.

When connected with motor, it is capable of supplying up to 320 Amps (forward) or 160Amps (backward) of continuous motor current. Its integrated Battery Eliminator Circuit (BEC) powers the receiver from the motor battery, with automatic cutoff of the motor power to preserve receiver power as the battery becomes depleted. It is small and powerful, which can be used for different type of ship or car.

Key Features

• Battery Compatibility: Supports 2-3S LiPo (7.4–11.1 V) and 5–9S NiMH/NiCd (6–10.8 V) batteries.

• BEC Output: Provides 5V/2A to power the receiver and other onboard electronics directly, eliminating the need for a separate receiver battery.

• Continuous Current:

  • Forward: 320A.

  • Reverse: 160A.

• Automatic Cutoff: BEC ensures the receiver stays powered by cutting off motor output when battery is low to avoid loss of control.

• Physical Dimensions: 43mm x 29mm x 27mm; compact for its capacity.

• Cable Specs: 16 AWG silicone wires; 140mm for battery/motor, 450mm to receiver.

Applications

• Suitable for RC cars, boats, and ships using brushed motors.

• Compact, suitable for medium to high power setups, with BEC for convenience.
