• IC Type: HT12E Encoder IC
• Operating Voltage: Typically operates within a voltage range of 2.4V to 12V, providing flexibility for various applications.
• Data Encoding: Converts parallel data inputs into serial data output suitable for transmission over radio frequency (RF) or infrared (IR) communication channels.
• Address Coding: Allows for address coding for secure communication between transmitters and receivers.

• 4-Bit Binary Adder with Fast Carry

• High-level input voltage: 2V

• Low-level input voltage: 0.8V

• High-level output current: -0.4mA

• Low-level output current: 8mA

• No. of Channels: 1

• Input clamp voltage: -1.5V

• Propagation delay time: 30ns

• Supply voltage range: 4.75 to 5.25V

• Package: DIP-16

• 74LS83 4-Bit Binary Adder IC

• 10-bit resolution

• ± 1 LSB max DNL

• ± 1 LSB max INL

• 4 (MCP3004) or 8 (MCP3008) input channels

• Analog inputs programmable as single-ended or pseudo-differential pairs

• On-chip sample and hold

• SPI serial interface (modes 0,0 and 1,1)

• Single supply operation: 2.7V - 5.5V

• 200 ksps max. sampling rate at VDD = 5V

• 75 ksps max. sampling rate at VDD = 2.7V
